40-60 Mesh / Minute Perforated Metal Machine Computer Automatically Control

Brand Name : JG

Model Number : JG-CKW

Certification : CE,ISO9001

Place of Origin : Hebei,China

MOQ : 1 set

Payment Terms : T/T, L/C, Western Union

Supply Ability : 15 sets per month

Delivery Time : 30 days

Packaging Details : nude packing

Width : 1250mm

Material : Galvanized steel plate with rolls

Colors : as required

Type : automatic

Speed : 40-60 Mesh/minute

After-sales service : Engineers available to service overseas

Price : 10000US$

Contact Now

Throat Metal Sheet Perforated Metal Machine / Perforated Metal Netting Machine

Description

1. Computer automatically control.Different shapes and sizes of perforated metal can be made.
2. Perforated metal machine is easy for handling and operation.Increased throat deep and working area.
3. Adopts horizontally placed crankshaft.
4. Rigid rotated bond clutch.
5. Manual shut height adjustment with scale display.
6. The type with "A" equipped with emergency stop device,which could make the slide stop at 0o-135o area and equipped with light curtain protector as well.
7. Punching plate thickness:1mm-12mm

Main technical parameters

Model	Width	The biggest thickness	The precision of hole-punching	speed (mesh/minute)	Power	Weight Ton	Outside size (mm)
Ckw-1000	1000	1.2mm	0.1mm	40-60	380v 50Hz	2.2	1500x1600x1500
Ckw-1250	1250	2mm	0.1mm	40-60	380v 50Hz	4.6	2300x2200x2150
Ckw-1250B	1250x2500	≤8mm	0.1mm	55-65	380v 50Hz	12	4800x2500x2400

Applications

1. Auto parts: automobile body covering parts, braking, fuel tanks, chassis, axle case, bumper

2. Household appliance: washing machine, TV, refrigerator, air conditioning, rice cooker and other parts
3. Kitchenware: sink, tea set and Other kinds of containers.
